Product Features:
3.0tons electric forklift trucks are widely used for loading, unloading and transporting the packaged goods in the factories, warehouses, stations, docks, ports and other places. Because of the characteristics of the forklift truck with low noise, flexible operation, no pollution, no smell, electric forklift trucks are particularly suitable for tobacco, textile, food, printing and other industries.
Specification for QINGONG 2.5T electric forklift trucks
General |
Brand |
QINGONG |
||
|
1 |
Model |
CPD30J |
||
|
2 |
Rated capacity |
kg |
3000 |
|
|
3 |
Load center |
mm |
500 |
|
|
4 |
Power type |
Battery |
||
|
Dimensions |
5 |
Lifting height |
mm |
3000 |
|
6 |
Free lifting height |
mm |
80 |
|
|
7 |
Turning radius |
mm |
2350 |
|
|
8 |
Overall length |
mm |
3705 |
|
|
9 |
Overall width |
mm |
1240 |
|
|
10 |
Overall height |
mm |
2200 |
|
|
11 |
Overall height |
mm |
4260 |
|
|
12 |
Overall height |
mm |
2200 |
|
|
13 |
Fork length |
mm |
1220 |
|
|
14 |
Fork width |
mm |
125 |
|
|
15 |
Fork thickness |
mm |
45 |
|
|
Performance |
16 |
Max. driving speed |
km/h |
14/16 |
|
17 |
Max. lifting speed |
mm/s |
290 |
|
|
18 |
Max. traction |
kn |
12 |
|
|
19 |
Gradeability |
% |
15 |
|
|
20 |
Tilting angles |
° |
6/12 |
|
|
21 |
Service weight |
kg |
4900 |
|
|
Motor |
22 |
Traction motor |
XQ-10-1C |
|
|
23 |
Lifting motor |
XQD-13-3S |
||
|
Battery |
24 |
Battery type |
40-DA-500 |
|
|
25 |
Battery voltage/capacity |
V/Ah |
80/500 |
|
3.0Ton Electric Counterbalance Forklift truck details:
1.The newly designed wide view mast enlarges operators' view effectively and lessens the blind area to provide a clearer vision.
2.Excellent steering system
3.The steering system with new technologies not only provides a smoother swerve and faster positioning and steering, but also effectively lowers down the noise.
4.The wonderful combination of high power AC motor and the new style gearbox b independent R&D fully enhance the performance of acceleration, driving and grade ability.
5.The electric forklift truck equipped with more intelligence functions not only ensures the safety performance, but also improve the efficiency and reduces energy consumption.
