Technical Data |
Unit |
WT1100 |
|
|
A |
Overall Operating Height |
mm |
4086 |
|
B |
Height to Bucket Hinge Pin |
mm |
3150 |
|
C |
Height to Top of Cab |
mm |
2028 |
|
D |
Height to Bottom of Level Bucket |
mm |
2960 |
|
E |
Overall Length without Bucket |
mm |
2833 |
|
F |
Overall Length with Bucket |
mm |
3623 |
|
G |
Dumping Angle at Maximum Height |
40° |
|
|
H |
Dumping Height |
mm |
2465 |
|
I |
Dumping Reach |
mm |
610 |
|
J |
Rollback of Bucket on Ground |
30° |
|
|
K |
Rollback of Bucket at Full Height |
94.6° |
|
|
L |
Wheelbase |
mm |
1150 |
|
M |
Ground Clearance |
mm |
210 |
|
N |
Angle of Departure |
26° |
|
|
O |
Turning Radius Front without Bucket |
mm |
1350 |
|
P |
Front Turning Radius |
mm |
2210 |
|
Q |
Rear Turning Radius |
mm |
1786 |
|
R |
Rear Axle to Bumper |
mm |
1070 |
|
S |
Tread Width, Centerline to Centerline |
mm |
1506 |
|
T |
Width |
mm |
1850 |
|
U |
Bucket Width |
mm |
1980 |
